ADDITIONAL SUPPORT FOR DPH 4xX GROUND-MOUNTED STRUCTURE
Application: for a two-support mounting table, landscape orientation, module size 113.5 cm / 220 cm

This support is used to extend a mounting table (increasing the number of modules on the structure) or as an additional support for a ground-mounted system (e.g., when installing bifacial panels).
Kit contents:
Bolt set "1" for JPH, JPV, DPH4, DPH5 (x4)
Bolt set "3" for DPH4, DPH5 (x4)
Oversized washer M10, 300HV, ISO 7093 (x5)
Angled beam 120x60x2 (4730 mm) for ground-mounted structure - DPH4-A1-003
Connector piece 53x53x2.5 (385 mm)
Front support 110x60x2 (2421 mm)
Rear support 110x60x2 (3806 mm)
Strut 53x53x2.5 (1120 mm)
Serrated flanged hex nut A2 M10 (x5)
Hammer-head bolt A2 M10x25 (x5)

Product warranty: 10 years

Note:
When adding an extra support, ensure that the appropriate quantity and length of profiles and connectors are included in your order. (bolt set no. 3), as well as mounting clamps.
Elementum PV shall not be held liable for the installation of ground-mounted structures in a manner that deviates from the instructions provided.
